Frame

• FORM™ Alloy
• Fully Sealed Cartridge Bearings
• Threaded Bottom Bracket
• Internal Cable Routing
• 2-Bolt ISCG05 Tabs
• RIDE-4™ Adjustable Geometry
• 160mm Travel
• FORM™ Alloy Rear Triangle

Suspension

• Fork: RockShox Zeb RC 170mm
  27.5 = 38mm Offset | 29 = 44mm Offset
• Front Travel: 170mm
• Shock: Fox Float X Performance
  Sealed Bearing Eyelet | 40x10mm F Hardware
  SM = 210x55mm | MD - LG - XL = 230x60mm
  Size-Specific Tune in FAQ
• Rear Travel: 160mm

Cockpit

• Headset: FSA ZS56/66 Reach Adjust
  0mm Cups Installed | +/- 5mm Cups Included
  Sealed Stainless 36°x45° Bearings
  Upper: 30.2mm x 41mm x 6.5mm
  Lower: 40mm x 51.8mm x 8.0mm
  1.5" Crown Race
• Stem: Rocky Mountain 31.8 AM | 5° Rise | 40mm
• Handlebar: Rocky Mountain AM
  760mm Width | 38mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
• Grips: ODI Elite Pro Lock On

Brakes & Drivetrain

• Brakes: Shimano MT6120 4-Piston | Metal Pads
• Shifter: Shimano Deore 12-speed
• Rear Derailleur: Shimano Deore 12-speed
• Crankset: Shimano Deore | 32T | 24mm Spindle
  Crankarm Length: SM = 165mm | MD - XL = 170mm
• Bottom Bracket: Shimano Threaded BBMT501-B
• Cassette: Shimano Deore 10-51T 12-speed
• Chain: Shimano M6100

Wheels

• Front Hub: Shimano TC500 | 15mm Boost
• Rear Hub: Shimano TC500 Boost 148mm
• Spokes: 2.0 Stainless
• Rims: WTB ST i30 TOUGH TCS 2.0 | 32H
  Tubeless Setup | Sealant Included
• Tires:
  Front: Maxxis Minion DHF 2.5 WT EXO Tubeless Ready
  Rear: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready
  Tubeless Setup | Sealant Included

Components

• Seatpost: X Fusion Manic Composite 30.9mm
  SM = 150mm | MD = 170mm | LG - XL = 200mm
• Saddle: WTB Solano Fusion Form 142 | Steel Rails
