Information
SPECIFICATIONS
- Frame FORM™ Alloy | Press Fit BB | Integrated Display | Internal Cable Routing | 197mm Rear Spacing | Tapered Zerostack Headtube | Dropper Post Compatible. Rear Triangle
- Fork Rocky Mountain Carbon Fat
- Headset FSA Orbit NO.57E ZS44|56 | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
- Stem Rocky Mountain 35 AM | 5° Rise | All Sizes = 40mm
- Handlebar Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 35 Clamp
- Grips Rocky Mountain Lock On Foam
- Brakes Sram G2 R 4 Piston | Resin Pads
- Shifter Sram NX-1E Eagle
- Rear Derailleur Sram GX Eagle
- Crankset and Chainring Race Face Ride Cinch 34T | 24mm Spindle | Crank Length: SM-MD = 170mm | LG-XL = 175MM
- Bottom Bracket Race Face BB124 24mm
- Cassette Sram XG-1275 10-52T
- Chain Sram NX Eagle. E-MTB Approved.
- Front Hub Rocky Mountain Sealed 150 x 15mm
- Rear Hub DT Swiss 350 197mm | 36T Star-Ratchet
- Spokes DT Swiss Champion 2.0
- Rims WTB KOM Light i76 | TCS Tubeless | 32 H | Tubeless Ready - Tape / Valves Included
- Tires F: VeeTire Snow Avalanche 27.5 x 4.5 120 TPI (Studs Included. Not Installed) // R: VeeTire Snow Avalanche 27.5 x 4.5 120 TPI (Studs Included. Not Installed) //
- Seatpost X Fusion Manic Composite 30.9mm | XS = 100mm | SM = 100mm | MD = 125mm | LG - XL = 150mm
- Saddle WTB Volt Race 142
- Drive System Dyname 4.0 Mountain Bike Drive | 700W Max Power | 250W Nominal Power | 108Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada
- Battery 720 Wh Removable Integrated Li-Ion | 100% Charged in 3:55 (4A) / 7:35 (2A) | 80% Charged in 2:55 (4A) / 6:05 (2A)
- Control Switch Rocky Mountain Micro Remote
- Display Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration
- Charger Rocky Mountain Powerplay FAST Charger V1 | 4A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4)
- Weight 53.702|24.41 KGS
