Race suspension

The new Maestro rear suspension system has a longer travel (160mm) and was developed and tested under the extreme conditions of the Enduro World Series races. The Trunnion mount shock has a longer stroke (62.5mm compared to 60mm on the previous generation). The Advanced Forged composite swingarm offers more stiffness while reducing the bike's weight.

Adjustable enduro geometry

The new Flip Chip technology lets you choose between three settings depending on the terrain. You can select a head tube angle of 63.5, 63.9, or 64.2 degrees, and a corresponding seat tube angle of 78.3, 78.7, or 79 degrees, resulting in a bottom bracket drop of 35, 30, or 25mm (size M) to adjust the bike according to terrain, your style, or rear wheel size.

Rear wheel options

The rider can now choose between a 29 or 27.5-inch rear wheel. A 29-inch wheel offers more stability and makes it easier to roll over obstacles, while a 27.5-inch wheel provides a more agile and playful ride. It's now easier than ever to tailor your bike to your style.

• Frame
  Advanced-Grade Composite front and rear triangles, 160mm Maestro suspension, flip chip, 12x148mm thru-axle, 27.5 or 29-inch rear wheel compatible, flip chip - Maestro 3, integrated downtube storage
• Fork
  Fox 38 Performance Elite, 170mm, GRIP 2 damper, 15x110 Kabolt X, 44mm offset, custom tuned for Giant
• Shock
  Fox Float X2 Performance Elite, 205/62.5, custom tuned for Giant
• Handlebar
  Giant Contact SLR TR35, composite, 800x35mm, 20mm rise
• Grips
  Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
• Stem
  Giant Contact SL 35 S:40mm, M:40mm, L:40mm, XL:40mm
• Seatpost
  TranzX travel-adjustable dropper, remote S: 120-150mm travel / 30.9 x 459mm
• Saddle
  Giant Romero SL
• Shifters
  SRAM GX Eagle, 1x12
• Front derailleur
  N/A
• Rear derailleur
  SRAM GX Eagle
• Brakes
  Shimano SLX M7120, hydraulic, Shimano RT-66 rotors [F]220mm, [R]200mm
• Brake levers
  Shimano SLX BL-M7100
• Cassette
  SRAM GX XG-1275 Eagle, 10x52
• Chain
  SRAM GX Eagle
• Crankset
  SRAM GX, DUB, 32t, 55mm chainline S:165mm, M:170mm, L:170mm, XL:170mm
• Bottom bracket
  SRAM DUB, press fit
• Rims
  Giant TRX 2 29 Carbon WheelSystem, 30mm inner width
• Hubs
  [F] Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt
• Spokes
  Sapim
• Tires
  [F] Maxxis Assegai 29x2.5 WT, 3C MaxxTerra, EXO+, TR [R] Maxxis Minion DHR II 29x2.4 WT, 3C MaxxTerra, DD, TR tubeless
• Extras
  Tubeless ready, 2.5" max tire size, 36t max chainring size, MRP AMG CS chain guide, 3M tailgate protector
