Marin

Rift Zone 1

$2,199.00
$2,199.00
$2,199.00
Financing available {"loading" => "lazy"}
In stock
The Marin Rift Zone 1 is your gateway to the Rifty family, designed to push the limits...
Hue: Black Grey
Size: XS (27.5)
Subtotal: $2,199.00

Livraison gratuite 100$ et plus (Exclus les vélos)

{"loading" => "lazy", "sizes" => nil, "widths" => "165, 360, 535, 750, 1070, 1500"}

Fast delivery

{"loading" => "lazy", "sizes" => nil, "widths" => "165, 360, 535, 750, 1070, 1500"}

Digital assistance

{"loading" => "lazy", "sizes" => nil, "widths" => "165, 360, 535, 750, 1070, 1500"}

Secure payments

{"loading" => "lazy", "sizes" => nil, "widths" => "165, 360, 535, 750, 1070, 1500"}

Quality products

002-BLACK_GRAY

Rift Zone 1

$2,199.00
001-BLACK_PURPLE
002-BLACK_GRAY

Rift Zone 1

$2,199.00
Hue: Black Grey
Size: XS (27.5)

    Information

    The Marin Rift Zone 1 is your gateway to the Rifty family, designed to push the limits of your riding without pushing your budget. It features super reliable X-Fusion suspension, an X-Fusion Manic dropper post, grippy Vee Crown Gem tires, plenty of Shimano components, and a hand-picked selection of our favorite Marin parts.

    Specifications

    Frame Series 3 6061 Aluminum, 27.5 or 29" Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB with ISCG05 Tabs
    Front Suspension X-Fusion Slide (29) or Sweep (27.5) Boost RC, 140mm Travel, Compression and Rebound Adjustment, 44mm Offset
    Rear Suspension X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom
    Rim Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
    Rear hub Shimano HB-MT200B, 141 QR, Centerlock, Standard Freehub Body
    Front hub Shimano HF-MT400B, 110x15mm, Centerlock
    Spokes 14g Black Stainless Steel
    Tires Vee Tire Snap WCE 2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless Compatible
    Rear Derailleur Shimano RD-U6000, 11-Speed GS
    Shifter Shimano, SL-U6000-11R, 11-Speed
    Crankset Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, 170mm Crank Length, Boost Spacing
    Bottom Bracket External Sealed Cartridge Bearing
    Chain Shimano LG-500 11-Speed
    Cassette Shimano CS-LG400-11, 11-Speed, 11-50T
    Front Brake Tektro HD-M280 Hydraulic Disc, 180mm Rotor
    Rear Brake Tektro HD-M280 Hydraulic Disc, 180mm Rotor
    Brake Levers Tektro HD-M280
    Handlebar Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
    Stem Marin 3D Forged Alloy, 35mm
    Grips Marin MTN, Closed End
    Headset FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
    Seatpost X-Fusion Manic, 1x Composite Remote, Size XS-S 150mm Travel, Size M-XL 170mm Travel, 30.9mm
    Saddle Marin Speed Concept

    Geometry

    XS S M L XL
    Stack 569.1 600.7 605.2 637.3 641.8
    Reach 415 430 450 485 515
    Head Tube Angle 65.5° 65.5° 65.5° 65.5° 65.5°
    Head Tube Length 115 120 125 125 130
    Seat Tube Length 330 390 400 425 430
    Seat Tube Angle 77° 77° 77° 77° 77°
    Effective Top Tube 552.6 568.7 589.7 632.1 663.2
    Bottom Bracket Height 339 339 339 343 343
    Bottom Bracket Drop 20 20 20 35 35
    Chainstays 430 430 430 430 430
    Wheelbase 1147.8 1164.8 1186.9 1234.4 1266.3
    Standover Height 661.7 677.8 687.8 701.7 700.5
    Fork Offset 44 44 44 44 44
    Seatpost Diameter 30.9 30.9 30.9 30.9 30.9
    Handlebar Width 780 780 780 780 780
    Stem Length 35 35 35 35 35
    Crank Length 170 170 170 170 170
