MODERN DESIGN

The tapered* head tube, single chainring drivetrain, rear derailleur equipped with a clutch, thru-axle hubs*, internal cable routing (including compatibility with a dropper post), and integrated chainstay protection provide you with everything you need to build your confidence and skills on the trails. (*certain models)

ALL-TERRAIN CONTROL

The new geometry is optimized for trail riding, with two wheel size options ([27.5] or [29] inches) depending on the frame size. It is also designed to match front suspension travel with an 80 mm or 100 mm fork. All models offer clearance for high-volume tires (up to 2.4 inches) for better grip on technical terrain.

LIGHTWEIGHT AND DURABLE

The all-new ALUXX aluminum frame features an updated tube shape and is lighter for improved trail performance.

SPECIFICATIONS

• Frame: ALUXX-grade aluminum, disc
• Fork: Giant SXC32-3 RL, coil spring, 1.5" tapered alloy steerer, 15x110mm thru-axle
• Handlebar: Giant Connect Trail, 31.8mm
• Grips: Giant Sole-O
• Stem: Giant Sport, 7-degree
• Seatpost: Giant Sport, 30.9
• Saddle: Giant ErgoContact Trail
• Pedals: platform
• Shifters: microSHIFT Advent, 1x9
• Rear derailleur: microSHIFT Advent RD-M6195M with clutch
• Brakes: Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm
• Brake levers: Tektro HDC M275
• Cassette: microSHIFT Advent, 9-speed, 11x46
• Chain: KMC X9
• Crankset: ProWheel Charm, [27.5] 32t, [29] 30t, 52.5mm chainline 32t
• Bottom bracket: cartridge
• Rims: Giant GX03V [27.5] or [29], alloy, double wall, 21mm IW
• Hubs: alloy, sealed bearing, [F] 15x110 thru-axle, [R] 12x142 thru-axle
• Spokes: stainless
• Tires: Maxxis Rekon [27.5]x2.4" or Maxxis Rekon Race [29]x2.4", 60 TPI, wire bead
• Extras: 2.4" max tire size, max chainring 32t
